CNC platform punch pressing hydraulic hole punching machine
1. Industrial computer numerical control system, AMADA company development numerical control processing software, can achieve the field programming, backstage programming; 19 inch brand LCD monitor, the picture is more clear and beautiful; Software convenient operation, bring their own mould library management, can identify CAD drawings automatically generate CNC code, and realize the automatic programming, automatic feeding, automatic stamping, high speed, high accuracy.
2. Adopts our company independent research and development the in-line arrangement die-set, can realize the automatic changing mould, match the internationally used standard mould and easy to change.
3. Servo motor, linear guide rail, ball screw, coupling and pneumatic components and electrical parts were imported brand. To ensure the machines’ accuracy and stability
4. Use centralized lubricating system, automatic return oil, ball screw , guide and other major transmission parts are f centralized lubrication, prolong the machines’ service life.
| No. | Item Catalogry |
| 01 | AMD-H thick plate CNC punching machine AMD-H |
| 02 | AMD-PQ platform CNC punching machine |
| Max. Length *Width | 1000*1000mm /1250*1000/2500*1250/4000*1250 |
| Max. Process Thickness | 6mm |
| Linear Feeding Speed | 20m/min |
| Rated Power | 2KW |
| Feeding Accuracy | ±0.15mm |
| Machine Size (length*width*height) | 3200*1700*900 |
| Environmental Conditions of the Machine | |
| Power | 380V ± 10%, 50HZ |
| Temperature | 5 - 40°C (for machine operation) |
| Relative Humidity | 20 – 80%RH |
| Note | 1. Keep this machine away from a strong shock source and electromagnetic source. 2. Free from harmful and corrosive gas and dust. |
Advantages
1. The activity of designing strive for the maximum cost performance.
2. According to the requirement of users,
design & develop personalization product & service.
3. According to the requirement of users, develop the best solution,
minimize the cost of users.
4. 24-hours efficient & confederate after sale commitments in the country.
1. Installation and commissioning issue:
We will send 1-2 technicians to assist with machine installation and commissioning,
customer pays for their tickets, hotel and diet, etc Customer need arrange
3-4 skilled worker and prepare insallation machinery and tools.
2. Warranty time:
12 months from date of commissioning completion, but no more than 18 months from date of delivery.
3. Supply full English documents:
including foundation drawings, manual book, electric wiring diagram, electric manual book and maintenance book,etc.
